P-touch Template Command Reference
- 7 -
2. P-touch Template Settings Tool User’s Guide
(12) FNC1 replacement setting
This setting selects whether or not GS codes, which are included in barcode protocols such as
GS1-128 (UCC/EAN-128), are replaced with FNC1 codes.
If the check box is selected, a received GS code is replaced with the FNC1 code. If the check box is
cleared, a received GS code is outputted as is.
(13) Number of copies setting
Specify the number of copies. A number between 1 and 99 can be specified.
(14) Print quality setting
Select the print quality setting. If the check box is selected, priority is given to the print quality.
If the check box is cleared, priority is given to the print speed.
(15) Cut at End setting
If this setting is selected, the cut operation will be performed when printing is finished.
(16) Cut number setting
A number between 1 and 99 can be specified.
(17) Auto cut setting
If auto cutting is selected, the cut operation will be performed after the number of labels specified in
(16).
(18) Communication settings
Settings can be specified for the following parameters for serial communication.
Baud rate
115200 bps, 57600 bps, 38400 bps, 31250 bps, 28800 bps, 19200 bps,
14400 bps, 9600 bps, 4800 bps, 2400 bps, 1200 bps, 600 bps, 300 bps
Bit length (bits) 8 bits, 7 bits
Parity None, Odd, Even
Busy control DTR, XON/XOFF
Returns the four parameters
to their default settings.
Closes the Communication
Settings dialog box.
Applies the four settings
to the printer.
