P-touch Template Command Reference
- 54 -
7. Control Command Details
ESC iXa2 Specify non-printed text strings
ASCII: ESC i X a 2 n1 n2 n3 data
Decimal: 27 105 88 97 50 n1 n2 n3 data
Hexadecimal: 1B 69 58 61 32 n1 n2 n3 data
Parameters
01h≤n1≤15h
n2: 00h (Fixed)
n3: 01h (Fixed)
00h≤data≤FFh
Description
 Specifies the non-printed text string.
n1+(n2*256): Length of the text string (0 to 20) + 1
data: Text string (The maximum number of characters that can be set is 20 characters
(bytes).)
 This command is a static command.
Remarks
 Invalid if more than 20 characters have been specified
Example
 To specify the non-printed text string as “ABCD”:
Since the text string contains four characters, n1=05h and n2=00h. Therefore, the command will be as
follows.
ESC i X a 2 05h 00h 01h A B C D
(1Bh 69h 58h 61h 32h 05h 00h 01h 41h 42h 43h 44h)
