20

4.6 Accumulated data display

The controller currently calculates and saves the cumulative values of the total consumed
material and total injected cycles since the last data clear.

To watch the Cumulative Totals of Weight and Cycles:

 Press

key in Main screen while in Mode "0", or

 Press

key in Time Setting screen while in Mode "1", or

 Press

key in Speed Setting screen while in Mode "2", or

 Press

key in Time/Speed Setting screen while in Mode "3"

"Totals" screen will be displayed:

Total Weight
Total material supplied by Sterling SF-1000 unit
since the last clear operation

Total Cycles
Total injection shots since last clear operation

 Press to clear existing cumulative data (accumulation will restart from zero)

 Press to return to Main screen


Notes:

1) Weight and Cycle values are the accumulated values since the last accumulated data

clear/

2) The accumulated data values are updated each cycle.
3) Accumulative values of the process data are memorized during system shutdown,

and displayed again on repowering the system on again.
