Sterlco SF1000 Gravimetric Additive Feeder - Manual (Page 16)

16
4.4 Configuration Parameters setup
4.4.1 Set general working configuration parameter values - dosing screw type, operation
mode and hopper Max/Min Fill - before entering the specific job parameters.
While in Main screen:
 Press key to enter Maintenance screen
 Press < 4 > key to enter Parameters screen
Use the following setting procedure to enter or modify any of the 4 parameters:
 Select desired parameter. The parameter value field will be marked.
 Enter (by keyboard) desired new value, and press to make new value
active. The next parameter will be selected.
 If you want to switch to next parameter without modifying the present value, press
without pressing
 Pressing twice at any time will return you to the Main Screen
4.4.2 Setting installed screw number
Each dosing screw is marked by its identifying number:
"0" – Micro capacity 2 pellet/shot to 0.2 kg/h
"1" - Small capacity
0.1 – 3.5 kg/h*
"2"
– Medium capacity
0.4-10 kg/h
"3"
– High Capacity 0.6 – 20 kg/h
"4"
– Extra high capacity 1.0 – 35 kg/h
*There are two types of screw #1:
"1.1" Standard low capacity
"1.0" Special low capacity
 To change screw number, return to Parameters screen, select the Screw line and
set the new installed Screw number (using setting procedure described in 4.4.1)
 Proceed with other parameters or press to return to Main Screen
