CONTROL PANEL - DIESEL
APEX 86037630
8-14
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86187070
34-903026 1 LT,
INST
2
86186940
790787
1
LIGHT, WARNING, AMBER, IDEC
3
86186930
51387
1
LIGHT, WARNING, IDEC AP2M
4
86179330
791069
1
DEC, INSTR PNL, APEX D
5
86056000
791068
1
PNL, INST APEX DIESEL
6
86175680
140702
2
BRKT, WIKA MOUNTING
7
86189050
790464
3
NUT, WELL 1/4-20 HD
8
86273180
00-000078
3
SCR, 1/4-20 X 1” HXHD GRD8
9
86175600
140624
2
BRKR, CIRCUIT, 15A
10 86230070 140634 1 BREAKER,
20AMP THERMAL CIRCUIT
11
86175610
140625
1
BRKR, CIRCUIT, 30A
12
86193880
791086
1
SWITCH, IN, KUBOTA DIESEL
13
86255920
73811
2
STANDOFF, 6-32 X 1/2 HEX NYL
14
86246890
54092
1
METER, 0-60VDC HOUR
15
86181950
36227
1
GAUGE, VACUUM 30” HG
16
86181930
36225
1
GAUGE, 0-1500 PSI
17 86193760 32-900206 1 SW,
RTRY W/BYPASS NON-ILL
18
86177550
791102
1
CNTRL, THROTTLE APEX DIESEL
19
86010780
87162
1
WASHER, 1/4 SPLIT LOCK PLTD
20 86193850 730202 1 SWITCH,
4-WAY
21
86181960
36229
1
GAUGE, TEMP, DATCON
22 86270330 02-000066 4 FLATWASHER,
1/4
23
86180380
12-800101
1
ELL, 1/4FPx1/4 POLY BR
24
86180350
12-800035
1
ELL, 1/4FPx1/4T BR
25
86186950
791070
1
LIGHT, GLOW PLUG GRN, IDEC
26
86191740
35-900188
1
RELAY, ENG SHTDWN
27
86274750
70270
1
SCR, 1/4-20 X 3/4 HHCS PLTD
28
86005720
57106
1
NUT, 8-32 W/STAR WASHER PLTD
29 86136310 57086
4 NUT,
M5
HEX
30
86308810
-
1
TIMER, GLOW PLUG
