ENGINE - DIESEL
APEX 86037630
8-20
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86274830
70307
2
SCR, M8 X 80HHCS PLTD
2
86279130
87083
5
WASHER, 5/16 SPLIT LOCK PLTD
3 86278830 02-000143 5 WASHER,5/16
FLAT
PLTD
4
86182750
790980
2
GSKT, THERM OUT, KU.WG972
5
86181420 12-800361
1
FTTG, BRB 3/4PX1H BR
6
86180260 11-800401
1
ELL, 3/4 ST BR
7 86192510 35-900050 1 SENS.
TEMP
240
DEG
8 86187780 790909
1 MNFLD,
THERM
ADAPTER
9
86184020 10-805409
1
HOSE, HP 1/4 X 12 (1/4P X 1/4P)
10 86176610
791110
1
CAP, 1/4” FPT BRASS
11 86272720 11-800345
2
PLG, 1/4 SOCHD BRASS
12 86191300
790928
1
PULLEY FRONT, KUBOTA WG972
13 86136270
57053
1
NUT, M6 HEX ZINC PLATED
14 86273700
140644
3
SCR, M8 X 25MM SHCS SS
15 86193340 791137
1 START,
ENG,
D902
KUB
16 86175210 790993
1 BELT,
ENGINE
KUBOTA
D902
17 86136280 57054
1 NUT,
M8
18 86175450
790987
8
SCR, M10-1.25 X 20MM
19 86137280
87054
1
WASHER, M8 FLAT DIN125A PLT
20 86178830 790988
1 COVER,
THERMOSTAT
21 86046140
790922
1
BRKT, RIGHT ENG MTG
22 86051630
790962
1
PLT, OIL DRAIN MTNG
23 86046000
790115
1
BRKT, OIL DRAIN
24 86010780
87162
7
WASHER, 1/4 SPLIT LOCK
25 86274750
70270
4
SCR, 1/4-20 X 3/4 HHCS PLTD
26 86270330 02-000066 8 FLATWASHER,
1/4
27 86279140
87085
1
WASHER, M6 SPLIT LOCK DIN127B
28 86137310
87098
3
WASHER, M8 SPLIT LOCK
29 86191310
790929
1
PULLEY, REAR KUBOTA WG972
30 86277310
70827
5
SCR, M8-1.25 X 60MM SHCS PLTD
31 86180880
790992
1
FAN, ENGINE KUBOTA WG972
32 86274910
70325
1
SCR, 5/16-18 X 1.25 HHCS GR5PLTD
33 86176230 64-950519
1
CABLE, BAT X 71” RED
34 86005750
57113
1
NUT, 5/16-18 HEX NYLOCK
35 86194340
790969
1
THERM, CLNT, 180 DEG KUB WG972
36 86190590
791074
1
PLUG, OIL DRAIN DIESEL
37 86136640
70262
1
SCR, M8 X 20 HHMS PLTD
38 86180800 790914
1 ENG,
KUBOTA,
D902
39 86176050
790439
2
BUSH, HEYCO, 1” ID
40 86275860
70554
1
SCR, 3/8-16 X 3.5 HHCS GR5 PLT
41 86274000
70069
3
SCR, 3/8-16 X 3 HHCS GR5
42 86279510
87171
4
WASHER, 3/8 FLAT
43 86046130
790917
1
BRKT, LEFT ENG MTG
44 86288730
70184
1
SCR, 10-24 X 1/2 PHTC
45 86343490
-
1
GSKT, .882ID X 1.095OD X .06THK, COPPER
-
86190780
790989
-
PUMP, WATER, KUBOTA
NOT SHOWN
-
86182020
791138
-
GLOW PLUG, D902 KUB
NOT SHOWN
-
86189120
791129
-
OIL, CRANKCASE DIESEL
NOT SHOWN
-
86193290
790991
-
SPARK PLUG, ENGINE, WG972 KUB
NOT SHOWN
-
86187290
791139
-
MANUAL, OPERATION KUBOTA D902
NOT SHOWN
- 86185770
42-902309 - FILTER,
OIL
KUBOTA
NOT
SHOWN
-
86192910
791140
-
SOLENOID, ENG D902 KUB
NOT SHOWN
-
86174430
791117
-
ATTACH, THROTTLE CABLE TO ARM
NOT SHOWN
-
86272200
66073
-
PIN, COTTER 1/16” X 3/4” L PLTD
NOT SHOWN
- 86270330
02-000066 - FLATWASHER,
1/4
NOT
SHOWN
-
86192950
791120
-
SPACER, THROTTLE LINKAGE
NOT SHOWN
-
86193210
791130
-
SPG, THROTTLE RETURN, DIESEL
NOT SHOWN
