FRAME
APEX 86037630
8-4
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86030290
790970
1
ASSY, HOOD, APEX
2
86193550
00-000272
13
STUD, 1/4 TURN FAST #85 OV
3
86189660
58-700023
13
PAD, 1/4 TURN VIBR
4
86193220
02-000268
13
SPLITRING, RETAIN, 1/4 TURN
5
86191570
01-000259
13
RECEPT, SNAPIN 1/4 TURNFAST
6
86055840
790957
1
PNL, LOWER FRONT
7A
86179340
791103
1
DEC, LWR FR PNL, APEX D
7B
86179320
790958
1
DEC, LWR FR PNL, APEX
8
86277730
790465
4
SCR, 1/4-20 X 2.75 BHCS BLK
9
86005680
57047
4
NUT, 1/4-20 HEX NYLOCK
10 86270330 02-000066 4 FLATWASHER,
1/4
11
86275460
70481
1
SCR, 1/4-20 X 3/4 BHCS BLK
12
86233410
81270
2
CLAMP, 3/4 DIA CUSHION .460DIA
13
86005770
57119
2
NUT, 3/8-16 HEX NYLOCK
