FRAME
APEX 86037630
8-2
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86273180
00-000078
10
SCR, 1/4-20 X 1” HXHD GRD8
2
86010780
87162
16
WASHER, 1/4 SPLIT LOCK PLTD
3 86270330
02-000066 22 FLATWASHER,
1/4
4
86177090
03-000261
1
CLAMP, CABLE 1/2 I.D. 1/4 BLT
5
86054600
790010
1
PNL, BELT GUARD, REAR
6
86051620
790950
1
PLT, AIR FILTER
7
86274750
70270
6
SCR, 1/4-20 X 3/4 HHCS PLTD
8
86274000
70069
2
SCR, 3/8-16 X 3 HHCS GR5
9
86279510
87171
4
WASHER, 3/8 FLAT
10
86046160
790952
1
BRKT, CENTER HOOD
11
86046190
791100
1
BRKT, THROTTLE MTG
DIESEL ONLY
12
86273330
00-000286
3
SCR, CAP 1/4-20 X 2.75 HXHD
13
86005770
57119
2
NUT, 3/8-16 HEX NYLOCK
14 86043840 790793 1 ASSY,
FRAME
15
86005680
57047
3
NUT, 1/4-20 HEX NYLOCK
16 86055730 790927 1 PNL,
GRILLE
17
86270990
57090
4
NUT, 10-32 HEX NYLOCK SS
18
86279340
87139
4
WASHER, 3/16 FLAT
19
86186730
500886
1
LABEL, MAIN, APEX-D
20
86273260
00-000216
2
SCR, CAP 1/4-20 X 1/2 FLTSO
21
86043860
790947
1
ASSY, FRONT HOOD
22
86043850
790907
1
ASSY, REAR EN/HOOD MTG
23
86233410
81270
1
CLAMP, 3/4 DIA CUSHION .406DIA
24
86275430
70461
1
SCR, 3/8-16 X 3.5 HHTB GR5 PLTD
25 86192120 791119 2 SCR,
10-24 X 3/8 SHCS PLATED
DIESEL ONLY
26
86279470
87165
2
WASHER, #10 SPLIT LOCK PLTD
DIESEL ONLY
27
86177140
791118
1
CLAMP, THROTTLE CABLE
DIESEL ONLY
