WAND – ERGONOMIC SIX JET - OPTIONAL
APEX 86037630
8-62
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
86326900
-
1
WAND, ERGO TI
COMPLETE
1 86195560 791121
1 WAND/HEAD
WELDMENT
2A 86182820 17-803025
1
GUN, PRESS WASH TM
2B
86011740
-
1
YG5000 SPRAY GUN ASM
3
86188590
791122
1
NIPPLE, 1/4 X 5 SS
4
86175760
791123
1
BRKT, HNDL, CLMP
5
86277760
791124
2
SCR, 8-32 X 1/4 SHCS SS
6
86188280 11-800381
1
NIP, 3/8 X 1/4 HX SST
7
86177870 17-803036
1
CONN, 1/4FP X 11/16-16F BR
8
86193490 14-806512
1
STRNR, JET 50 MESH
9
86177860 17-803010
1
CONN, 1/4 X 11/16-16M
10
86005580
56012
1
NIP, 1/4 FPT QD
11
86195600
791127
1
WASHER, BLK WD
12
86195610
791128
1
WASHER, FLAT SS WD
13
86179020 48-941186
1
DEC, WD HD (CAST SST) TM
14
86177650 12-800060
1
CONN, 1/4P X 1/4T BR
15
86031580 10-805245
1
HOSE, 3/16 X 40-1/2
16 86183110 46-802553 1 HDL, TITANIUM WND W/SPYR
17
86182120
791125
1
GRIP, BLU HANDLE
18
86177150
791126
2
CLAMP, #38 HOSE SS
19
86194450 17-803018
2
TIP, SPRY 9501 X 1/8P SST
20
86270990
57090
4
NUT, 10-32 HEX SS NYLOCK
21
86194580 17-803078
4
TIP, SPRAY 8001 SST 1/8 VJE
22
86187620 52-502058
1
MNFLD, LT TITAN
23
86177710 12-800322
2
CONN, 1/8P X 1/4T COMP BR
24 86187610 52-502057 1 MNFLD,
RT
TITAN
25
86190180 11-800206
2
PLG, 1/8 SOCHD BR
26
86175660
140160
1
BRKT, MANIFOLD, WAND
27
86341590
-
6
CHECK VALVE, NOZZLE WD
- 86186100 47453
1 KIT,
REPAIR 17-803025
NOT SHOWN
