WATER PUMP
APEX 86037630 8-28
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86190490 11-800101 1 PLUG, 1/8P
2 86046050 790434 1 BRKT, 1/8 ALUM COUPLER
3 86177660 12-800065 1 CONN, 1/8P X 1/4T
4 86179900 31095 1 EL, 1/4 MJIC X 1/4 MBSPP
5 86180450 12-800347 1 ELL, 3/8P X 1/2T 45 DEG. BR
6 86175030 44-802250 2 BELT, AX38 GOODYEAR MATCH
7 86177520 790976 1 CLUTH, 2X BELT, P31
8 86282770 51372 1 LOOM, 1/4 HE TMP X 10”
9 86005770 57119 4 NUT, 3/8-16 HEX NYLOCK
10 86279510 87171 4 WASHER, 3/8 FLAT
11 86057150 790436 2 STRAP, WTR PMP HOLDDOWN
12 86277300 70826 4 SCR, M10-1.5 X 20MM SHCS PLTD
13 86279500 87168 4 WASHER, M10 SPLIT
14 86046150 790935 1 BRKT, WTR PMP MTG
15 86180360 12-800040 1 ELL, 1/8P X 1/4T BR
16 86191440 791173 1 PUMP, CHEM, PULSE, GP *(3) WAS 41-809158
17 86179920 790605 1 EL, 90 DEG 1/8 X 5/16 HB
18 86176990 03-000065 2 CLAMP, HOSE #4 SST
19 86181370 12-800278 1 FTTG, BRB 1/2P X 3/4H BR
20 86177020 03-000113 1 CLAMP, HOSE #12 SST
21 86191400 65241 1 PUMP, ASSY, GEN 4.5GPM, P31
22 86271970 57302 4 NUT, 3/8 PUSH PLATE
23 86195100 65245 1 VALVE CAP, 303 SST, INLET *(3) WAS 16-808237
24 86189290 65249 2 O-RING, DURO,.862ID X .103CS *(3) WAS 43-810079
25 86195110 65247 2 VALVE KIT, ASM, CHEM, PULSE PUMP *(3) WAS 42-809265
26 86173440 43-810105 1 O-RING, 1-5/8OD X 1-3/4 OD/40D VITON *(3)
27 86249220 65252 1 PLASTIC DISC *(3) WAS 42-809264
28 86179500 42-809047 1 DIAPHRAGM, CHEM PUMP
29 86194630 65250 1 PULSE PUMP, TOP COVER INLET *(3) WAS 52-502053
30 86191340 65253 1 PULSE PUMP, BODY *(3) WAS 52-502052
31 86173620 04102 1 ADAPTR, PULSE PMP, GEN PUMP
32 86195120 65248 1 VALVE CAP, 303 SST, OUTPUT *(3) WAS 16-808237
33 86192920 65246 1 SPACER CAP, 303 SST, OUTPUT *(3)
34 86190540 12-800029 1 PLUG, 1/4T BR *(4)
35 86177210 03-000051 1 CLMP, CABL 7/16 ID 1/4 BLT *(4)
*SEE SERIAL NUMBER PAGE.
**CALL MANUFACTURER FOR SERIAL NUMBER.
