HELI-COIL HEAT EXCHANGER
APEX 86037630
8-36
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86177560
15-808073
1
COCK, DRN 1/4P X 1/4 HOSE ELL
2
86197360
31016
1
ELBOW, 1/4NPT STREET
3
86177310
03-000248
2
CLMP, HOSE #16 1-1/2 MIN 1-3/4
4
86181420
12-800361
2
FTTG, BRB 3/4PX1H BR
5
86180260
11-800401
1
ELL, 3/4 ST BR
6
86180430
12-800326
2
ELL, 3/4PX1/2T BR
7 86180000 31093 1 ELBOW,
3/4” 45 DEG BRASS ST
8
86005770
57119
2
NUT, 3/8-16 HEX NYLOCK
9
86279510
87171
2
WASHER, 3/8 FLAT
10
86275860
70554
2
SCR, 3/8-16 X 3.5 HHCS GR5PLTD
11
86046060
790445
1
BRKT, RIGHT HOOD MTG
12
86233410
81270
1
CALMP, 3/4 DIA CUSHION .406 DIA
13
86191570
01-000259
1
RECPT, SNAPIN 1/4 TURNFA
14 86048290 57-520073 1 HE,
HELI-COIL
