WAND-TITANIUM SIX JET-OPTIONAL
APEX 86037630
8-60
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
86288350
89248
1
WD, TM, 6 JET, TITANIUM (8001) PC
COMPLETE
1
86273310
00-000282
2
SCR, CAP 1/4-20 X 1 1/4 SOC
2
86192030
00-000317
2
SCR, CAP 10-32 X 1 1/4 SOCH
3
86006680
70228
4
SCR, 10-32 X 1/4 PPHMS SS
4
86270990
57090
2
NUT, 10-32 HEX NYLOCK SS
5 86264910 04-000093 2 TIE,
CABLE
13”
6A 86184270
10-805504
1
HOSE, 3/16 X 46 (1/8P X 1/4FT) MET
6B 86337360
-
1
HOSE, 3/16 X 47 (1/8P X 1/4FT) MET
6C 86183720
-
1
HOSE, 3/16 X 47 5/8 (1/8P X 1/4FT) MET
7
86247680
56015
1
NIPPLE, 1/4 HEX
8
86190180
11-800206
2
PLUG, 1/8 SOCHD BR
9
86177650
12-800060
1
CONN, 1/4P X 1/4T BR
10 86177710
12-800322
2
CONN, 1/8P X 1/4T COMP BR
11 86005580
56012
1
NIPPLE, 1/4 FPT QD
12 86193490
14-806512
1
STRAINER, JET 50 MESH
13 86194450
17-803018
2
TIP, SPRAY 9501 X 1/8P SST
14 86195570 17-803006 2 WASHER,
NYLON
15 86177860
17-803010
1
CONN, 1/4P X 11/16-16M
16 86177870
17-803036
1
CONN, 1/4FP X 11/16-16F BR
17 86194580
17-803078
4
TIP, SPRAY 8001 SST \1/8 VJET
18 86340720
-
1
TRIGGER, WD VLV, 9 DEG
19 86174680 52-502008BK
1
BODY, WD HDL, 2” TB, BK
20 86198180
52-502009
1
HOLD DN-WD HDL 2” TUBE
21 86187610 52-502057 1 MANIFOLD,
LEFT
22 86187620 52-502058 1 MANIFOLD,
RIGHT
23 86174060 56-502548 1 ASSY, MNFLD S-BEND
24 86285440
56-502534
1
WD & HD, TITANIUM
25 86174120 61-950496 1 ASSY, EXTRACTOR VALVE
26 86193360
16-808189
1
STEM, EXTRACTOR VALVE
27 86193200
16-808190
1
SPRING, EXTRACTOR VALVE
28 86192410
16-808228
1
SEAT, EXTRACTOR VALVE
29 86183160
16-808229
1
HLDR, VLV STEM-EXTRACTOR VL
30 86189510
43-810062
1
O-RING, .114 ID .254OD
31 86189520
43-810063
1
O-RING, .551ID .691OD
32 86174500 43-810064 1 BACK-UP,
.250DIA
33 86174630
52-501590
1
BDY, EXTRACTOR VLV
34 86179250
48-941462
1
DEC, WD HD TITANIUM
35 86341590
-
6
CHECK VALVE, NOZZLE WD
MEASURE AND MATCH EXISTING HOSE LENGTH.
