86037630 pgs 8-24 and 8-25, Coolant system – Prochem Apex User Manual
Page 105
COOLANT SYSTEM
APEX 86037630
8-24
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86191530 790918 1 RADIATOR,KUBUTA
W/SHROUD
2
86055820
790953
1
PNL, FRONT RAD CLOSEOUT
3 86270330
02-000066 6 FLATWASHER,
1/4
4
86010780
87162
4
WASHER, 1/4 SPLIT LOCK
5
86274750
70270
4
SCR, 1/4-20 X 3/4 HHCS PLTD
6
86278380
70825
2
SHOULDER BOLT, 5/8 OD X 2.25L
7
86010730
87088
2
WASHER, 5/8 ID X 1.18 X .06 SS
8 86195590 790930 4 WASH,
.612IDX1.31OD, RAD, APEX
9
86189050
790464
2
NUT, WELL 1/4-20 HD
10
86177020
03-000113
4
CLAMP, HOSE #12 SST
11
86177310
03-000248
3
CLMP, HOSE #16 1-1/2 MIN 1-3/4
12
86176990
03-000065
2
CLAMP, HOSE #4 SST
13
86175820
140642
1
BTL, CLNT RECIV, PIN, 1 LTR
14
86273260
00-000216
2
SCR, CAP 1/4-20 X 1/2 FLTSO
15
86173590
790936
1
ADAPTER, Y COOLANT
16
86273180
00-000078
2
SCR, 1/4-20 X 1” HXHD GRD8
