VACUUM BLOWER
APEX 86037630 8-26
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86271070 57114 2 NUT, 7/16-14 HEX
2 86279510 87171 16 WASHER, 3/8 FLAT
3 86193230 04-000091 1 SPRING, VAC REL VLV
4 86180370 12-800099 2 ELL, 1/8P X 1/4 POLY BR
5 86179590 43-807106 1 DIAPH, VAC REL VLV
6 86180610 52-501684 1 ELL, VAC REL VLV
7 86057090 56-501994 1 STM-VAC REL VLV
8 86175390 140611 1 BLWR, TRI-FLOW
9A 86191320 790954 PULLEY, 2TB64 GAS ONLY
9B 86191110 44-802335 1 PULL, 2TB74 PERF 805 DIESEL ONLY
10A 86185390 790944 1 HUB, P1 X 1-1/4 GAS ONLY
10B 86185410 791115 1 HUB, Q1 X 1-1/4 DIESEL ONLY
11 86188540 52-502071 1 NIPPLE, VAC OUTL TRI-FLOW
12 86189610 43-810104 2 O-RING, 3-1/4 X 3-1/2 OD
13 86056810 790443 2 SPACER, BLOWER
14 86051520 790442 1 PLT, BLOWER ADJUST
15A 86174790 141039 2 BELT, GATES, BP46 PREDATOR *(2) GAS ONLY
15B 86174800 141040 2 BELT, GATES, BP48 PREDATOR *(2) DIESEL ONLY
16 86277740 790467 4 SCR, 3/8-16 X 1.25 SHCS PLTD
17 86275190 70377 4 SCR, 3/8-16 X 1.25 HHCS SS
18 86010790 87163 8 WASHER, 3/8 SPLIT LOCK
19 86274000 70069 4 SCR, 3-8-16 X 3 HHCS GR5
20 86005770 57119 4 NUT, 3/8-16 HEX NYLOCK
21 86273420 00-000336 2 SCR, CAP 3/8-16 X 3 ALL THD
22 86005730 57111 3 NUT, 3/8-16 HEX
23 86277750 791116 3 SCR, 3/8-16 X 1.25 HHMS GR8 PL
24 86049230 54-500412 1 KEY, 1/4 SQ X 1.88
*SEE SERIAL NUMBER PAGE.
**CALL MANUFACTURER FOR SERIAL NUMBER.
