HOSE REEL-OPTIONAL
APEX 86037630 8-80
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86191620 56-501962 1 REEL, VACUUM HOSE GRAY
2 86177270 03-000124 2 CLAMP, MFLR 1-3/4
3 86175990 52-501685 2 BUSHING, HOSE REEL
4 86174560 56-501960 1 BASE, HOSE RL (250’)
5 86175740 56-502207 1 BRKT, LOCKOUT HOSE REEL
6 86186870 61-950854 1 LATCH ASSEMBLY
7 86270330 02-000066 2 FLATWASHER, 1/4
8 86010780 87162 2 WASHER, 1/4 SLPIT LOCK
9 86274750 70270 2 SCR, 1/4-20 X 3/4 HHCS PLTD
10 86005650 57031 2 NUT, 5/16-18 HEX
11 86191820 56-501968 1 REEL, HP HOSE GRAY
12 86174740 45-802138 2 BEARING HOSE REEL
13 86278830 02-000143 4 FLATWASHER, 5/16
14 86279130 87083 4 WASHER, 5/16 SPLIT LOCK PLTD
15 86006750 70302 4 SCR, 5/16-18 X 1” HHCSGR5PLT
16 86181030 44-802122 4 FLANGE, 47MST
17 86174730 56-501961 1 BODY, HP HOSE GRAY
18 86277830 00-000072 10 SCR, 3/8-16 X 2” HXHD
19 86190170 50-500511 1 PLATE, INSTALL MT
20 86279510 87171 10 WASHER, 3/8 FLAT
21 86005770 57119 10 NUT, 3/8-16 HEX NYLOCK
22 86189850 55-501789 1 PIN, LOCK HOSE REEL
23 86175700 50-501812 1 BRKT, HOSE REEL LOCK
24 86193240 04-000302 1 SPRING, LOCK-LOCK PIN ASSY
25 86177190 04-000303 1 CLIP, RETAINER-LOCK PIN ASSY
