APC Smart-UPS VT User Manual
Page 21
Operation – Operation Procedures
990-2282A-001
Smart-UPS® VT 10-40 kVA 400V, 208V, 200V – Operation
15
How to use the Diags screen
The Diags.
View troubleshooting information.
Note
For more details on the Fault and Diagnostics screens, see the section Troubleshooting.
Chrg 100%
Load 000%
xxxVin 000Vout x0Hz
Runtime: 0hr 0m
Press
Control
Status
Setup
Logging
Display
Diags
Help
Use
Press
Fault & Diagnostics
System Information
Switch status
Diags Screen
Raw Status Dump
Use
Press
