1: General Description
3
1.3 Supplied Hardware
The PUB equipment is supplied in a rugged polypropylene carrying case fitted with a foam insert to give added
protection for transportation. The supplied components are shown in Figure 1.2.
Figure 1.2 Standard PUB equipment
Standard equipment
• PUB instrument with backlit graphic display.
• Power supply - with UK, US, European adaptors. 110/240 VAC.
• 4 to 20 mA/Pulse Output cable.
• 2 lengths of chain.
• Test block.
• Transducer cables (x2) 79 inches (2m) long.
• Transducer set (x2) – type ‘A’ or type ‘B’ depending on model.
• Set of transducer holders used for mounting the transducers.
• Ruled separation bar (2-piece).
• Ultrasonic couplant with syringe dispenser used when mounting the transducers.
• Manual.
4 to 20 mA /
Test Block
Power Supply
Pulse Output
Cable
Transducer Cables (x2)
Chains (x2)
Transducer
Transducers
(Sensors x2)
Ultrasonic Couplant
Ruled Separation bar (x2)
PUB Instrument
(Batt. Charger)
Holders (x2)
