3: Operating Procedures
11
3.1 Setting-up the Instrument
3.1.1 Using the instrument for the first time
Before you use your PUB for the first time you should first charge the battery, then select the display language
and set-up the internal clock, as described below.
Charging the battery
1. Connect the external battery charger to the charger socket at the bottom of the instrument then switch on the
utility supply.
Selecting a language
The first time you switch on the instrument you may be asked to select a user language.
1. Switch on the instrument by pressing the ON/OFF button.
2. If necessary, select the required language using the UP/DOWN scroll keys then press the ENTER key.
2. The instrument should indicate CHARGING and
an animated battery symbol indicates that the
battery is taking on charge.
3. Leave the instrument on charge for 6.5 hours
before using it for the first time.
CHARGING DD-MM-YY HH:MM:SS
3. The selected language will be the default when
the instrument is next used. To change the
language again select the
Change Language
option in the SETUP INSTRUMENT screen (see
below).
4. The initialization screen will be displayed, giving
details of the instrument’s serial number and
software revision details.
5. Press the ENTER key to start the instrument.
6. This is the MAIN MENU and is the starting point
for all the operations described in this chapter.
Note: Data Logger and RS232/USB functions are
not implemented on the PUB.
Serial# 0012345 V 00.00.000
Press to start
MAIN MENU DD-MM-YY HH:MM:SS
Quick start
View/Edit Site Data
Data Logger
Setup RS232 /USB
Setup Instrument
Read flow
