Page 22: Operating procedures
3: Operating Procedures
18
3.4
Managing Named Sites
If you want to monitor a particular site location frequently you can set up a named ‘Site’ to store the installation
details, such as pipe dimensions and material, required to set-up the PUB system. These can then be recalled
later when revisiting that particular location.
The instrument can store up to 20 sites, the first site is reserved for
QUICK START and cannot be renamed;
subsequent sites are initially named
EmptySite1 through to EmptySite19.
3.4.1 Setting up a new site
Note: The ‘Download & save current site’ option is disabled in the PUB range.
1.
Select
View / Edit Site Data from the
MAIN MENU.
2.
Select
Choose from list of sites.
3.
Select one of the
EmptySites from the
presented list (e.g.
EmptySite 1 as shown).
4.
Select
Site name and press the ENTER key.
VIEW EDIT SITE DATA
DD-MM-YY HH:MM:SS
Qxx.xx%
Choose from list of sites
Site name : EmptySite1
Dimensions : Inches
Pipe outside diameter: 4.00
Pipe wall thickness : 0.20
Pipe lining thickness: 0.16
5.
This opens the
ALTER NAME screen.
6.
Select
Alter the Site Name and you will be
presented with a screen which allows you to
enter a new name in much the same way as
when composing a mobile text message.
7.
On completion press the
ENTER key then select
Exit. This will take you back to the VIEW EDIT
SITE DATA screen.
ALTER NAME
DD-MM-YY HH:MM:SS
Site name : EmptySite1
Do you wish to:–
Alter the Site Name
Exit
8.
Scroll down through the menu list and enter/
change the pipe parameters and other data
pertaining to the site.
VIEW EDIT SITE DATA
DD-MM-YY HH:MM:SS
Qxx.xx%
Choose from list of sites
Site name : MyNewSite
Dimensions : Inches
Pipe outside diameter: 4.00
Pipe wall thickness : 0.20
Pipe lining thickness: 0.16
9.
When all the data is correct you can either:
a)
Select
Save current site & read
flow to continue fitting the transducers
and opening the
FLOW READING screen.
b)
Select
Delete this site to delete the
site name and values and restore it to the
original
EmptySite name.
c)
Select
Exit to return to the MAIN MENU.
Pipe wall material : Mild Steel
Lining material : ---------
Sensor set : A-ST
Sensor mode : Reflex
Fluid type : Water
Save current site & read flow
Delete this Site
Exit
