Troubleshooting – Dwyer Series PUB User Manual
Page 40
5: Troubleshooting
36
Gain
Gain values are typically in the range 600 to 850.
Switches
Typical Switches values are
None and *10. On small pipes (and when using the test block) the value should be
None. A Switch value of *100 indicates poor sensor set-up or poor connections.
UP/DN time difference
The difference in transit times between the upstream and downstream signals due to the fluid flow.
Fluid propagation rate
This is the sound speed of the fluid calculated using the data entered by the user.
Sensor separation
The same value as displayed in the setup screen.
