3: Operating Procedures
18
7. Select the pipe wall material from the list
provided, then press
ENTER.
If the material is not listed select Other and
enter the propagation rate of the pipe wall
material in meters/sec. Contact Dwyer if this is
not known.
8. If a lining thickness value was entered earlier,
this screen is displayed to request that you
enter the lining material type. If no lining
thickness was entered this screen will be
bypassed.
9. Select the lining material from the list provided
then press
ENTER.
If the material is not listed select Other and
enter the propagation rate of the lining material
in meters/sec. Contact Dwyer if this is not
known
10. Select the fluid type from the list provided and
press ENTER.
If the liquid is not listed select Other and enter
a propagation rate in meters/second.Contact
Dwyer if this is not known
11. If you need to alter the fluid temperature from
that shown select either °C or °F with the
cursor and press the ENTER key.
12. Enter the new temperature value and press the
ENTER key.
13. The new temperature should now be indicated
in both °C and °F.
14. Select Continue.. and press ENTER.
PIPE WALL MATERIAL * *
Select pipe wall material
Mild Steel
S' less Steel 316
S' less Steel 303
Plastic
Cast Iron
Ductile Iron
Copper
Brass
Concrete
Glass
Other (m/s)
PIPE LINING MATERIAL * *
Select pipe lining material
Steel
Rubber
Glass
Epoxy
Concrete
Other (m/s)
FLUID TYPE * *
Select fluid type
Water
Glycol/water 50%
Glycol/water 30%
Lubricating oil
Diesel
Freon
Other (m/s) ––
FLUID TEMPERATURE * *
Enter Fluid Temperature
°C: 5.00
°F: 41.00
Continue..
