3: Operating Procedures
16
3.1
Setting-up the Instrument
3.1.1 Using the instrument for the first time
Initial user language selection
The first time you power-up the instrument you will be asked to select a user language, which will then be the
default language when the instrument is next used. If you want to change the language when the instrument is in
use, see below.
1.
On initial power-up, the start-up screen will be
displayed for 5 seconds, showing the
instrument's serial number and software
revision.
2.
After 5 seconds, the available language list will
be displayed.
3.
Select the required language and press
ENTER.
4.
The instrument will display the
MAIN MENU.
The MAIN MENU screen
The
MAIN MENU screen is at the top of the menu
hierarchy and is the starting point for all the
operations described in this chapter. This screen is
normally accessed from the
FLOW READING screen
by pressing the
ENTER key.
Note: If you make a mistake when entering the data press the
Delete key to move the cursor back to the
number you wish to change, then continue. If you enter an invalid number an ‘
ERR:Invalid Date or Time!’
error message is displayed on the second line of the screen. If this occurs repeat the set date/time procedure.
3.1.2 Changing the user language
If you want to change the user language at any time
after the instrument has been put into operation:
1.
Select
Setup Instrument from the MAIN
MENU then press ENTER.
2.
Select
Change Language from the SETUP
INSTRUMENT screen then press ENTER.
3.
Select the required language from the list
provided and press
ENTER.
4.
The instrument returns to the
MAIN MENU.
Key Point: When the instrument used for the first time the operator has free access to
all the set-up and operating menus until the instrument is put into FLOW READING
operation, where-upon all the menus become password protected (see page 19).
Serial# 0012345 V 00.00.000
Please wait.........
MAIN MENU
* *
Quick start
View/Edit Site Data
Data Logger
Setup RS232 /USB
Setup Instrument
Read flow
SETUP INSTRUMENT
* *
Set Date & Time : dd-mm-yy hh:mm:ss
Calibrate 4-20mA
Factory settings
Change Language
Exit
