4 Configuration parameters
74
4.2.8 Configuration - Control functions
4.2.9 Configuration - Texts
Parameter Value/Selection Description
External texts:
Binary input 1 — 4 Configuration
➔ Control functions
➔ External texts
➔ Binary input
1 … 4
Standard text,
Text 1 — 18,
No text
v Chapter 3.5 “Event list”
v Chapter 4.2.9
“Configuration - Texts”
External texts:
Logic channel
1 — 6 Configuration
➔ Control functions
➔ External texts
➔ Logic channel
1 — 6
Standard text,
Text 1 — 18,
No text Can only be used if the
“Math/logic module”
option is available.
v Chapter 3.5 “Event list”
v Chapter 4.2.9
“Configuration - Texts”
Key inhibit Configuration
➔ Control functions
➔ Key inhibit
Off,
Bin. inp. 1 — 4,
Logic channel 1 — 6,
Low alarm 1 — 6,
Low comb.al.,
High alarm 1 — 6,
High comb.al.,
Count/Int/Al 1 — 6,
C/i. comb.al.,
Comb. alarm,
CF inserted,
IntMemAlmCF,
IntMemAlmSer,
MemAlmCFcard,
Error, Modbus flag, The keys will be locked as
soon as the selected
signal is activated
Parameter Value/Selection Description
Texts Configuration
➔ Texts
➔ Text1 — 18
20 characters
Text 1 — 18
