4 Configuration parameters
66
4.2.4 Configuration - Math channels
4.2.5 Configuration - Counter/integrator (extra code)
Parameter Value/Selection Description
Scaling start Configuration
➔ Math channels
➔ Math channel 1 — 6
➔ Scaling start
-99999 to 0 to +99999 Scaling start of a math
channel.
The setup progam is used
to determine what is
involved in a math channel.
Scaling end Configuration
➔ Math channels
➔ Math channel 1 — 6
➔ Scaling end
-99999 to +100 to +99999 Scaling end of a math
channel.
The setup progam is used
to determine what is
involved in a math channel.
Parameter Value/Selection Description
Channel Configuration
➔ Counter/integrator
➔ Counter/int.chans.
1 — 6 Select channel for which
the subsequent
parameters are to be
configured.
Function Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Function
Off,
Counter
Integrator,
Oper.time First select the required
function.
v Chapter 2.5 “Counters /
integrators / operating
time counter”
Type Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel 1 — 6
➔ Type
Periodic,
External,
Daily,
Weekly,
Monthly,
Aearly,
Total,
DailyFrom-To Reporting period.
Select here when the count
value is to be stored and
reset.
Input signal Configuration
➔ Counter/integrator
➔ Counter/int.chans.
➔ Channel — 6
➔ Input signal
Off,
Bin. inp. 1 — 4,
Logic channel 1 — 6,
Low alarm 1 — 6,
Low comb.al.,
High alarm 1 — 6,
High comb.al.,
Count/Int/Al 1 — 6,
C/i. comb.al.,
Comb. alarm,
CF inserted,
IntMemAlmCF,
IntMemAlmSer,
MemAlmCFcard,
Error, Modbus flag, The parameter can only be
programmed if “Counter”
or “Operating time” has
been selected under
Function.
Please select which event
is to be counted.
