2 Device description
28
2.11 Webserver
If the paperless recorder is equipped with the extra code “Ethernet interface”,
and the device-internal Ethernet software (“Ethernet version“) has the number
183.02.03 or higher, then the paperless recorder has an inbuilt webserver. The
webserver can be started by entering the IP address in an Internet browser on
the PC (e.g. http://10.10.90.45).
The variables that are shown are acquired and displayed automatically by the
webserver. The latest data are read out of the instrument every 5 seconds. Any
limit infringements show a red background. A maximum of 6 channels (analog
or math channels), up to 6 counters or integrators, and a maximum of 6 event
traces.
Device name
Analo
g
channels
Counters / integrators
Event trac
es
