65
4 Configuration parameters
External
cold junction
temperature Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Ext. CJ temp.
-50 to +150°C External cold junction
temperature for
thermocouples
Range
start Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Range start
any value
0mA
Range
end Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Range end
any value
20mA
Start temperature Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Start
temperature
any value Only for sensor: current or
voltage with linearization,
resistance thermometer,
thermocouple.
Only for signals that have
not yet been linearized.
End temperature Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ End temperature
any value Only for sensor: current or
voltage with linearization,
resistance thermometer,
thermocouple.
Only for signals that have
not yet been linearized.
Scaling start Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Scaling start
-99999 to 0 to +99999
Scaling end Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Scaling end
-99999 to +100 to +99999
Filter constant Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Filter constant
0.0 — 0.1 — 10.0s
Parameter Value/Selection Description
