9 math/logic, Math/logic, 5 setup program – West Control Solutions DataVU 5 User Manual
Page 105
105
5 Setup program
5.9 Math/logic
The math and logic module is available as an extra code. It has to be ordered
from the start, or subsequently enabled through the function Extras ➔ Enable
extra codes (Page 98).
The math/logic module is composed of channels that are not available as
hardware but are calculated by the instrument software.
Math
You can activate the math channels in the setup program, in the “Math / logic”
area, or through the menu Edit
➔
Settings through setup only
➔
Math / logic.
In the following example, math channel 3 will be configured:
