51
3 Operation and visualization
CompactFlash
card
H
The function CF card  Update reads out data that have not been
read out yet. After read-out, the data are marked as read in the
recorder.
The function Total meas. data
 CF card reads all the data from
the internal memory, including those that had already been read
out.
Residual capacity of CF card in percent
Background flashes on error (e. g. “CF
card full”, “no CF card”,
or in the event of a memory alarm
Start action
The configuration data are read from the CF card
The configuration data are written to the CF card
All measurement data in the memory are written to CF card
Measurement data not yet saved are written to the CF card.
Select action
Counter/integrator reporting periods are concluded and
written to the CF card, together with the measurement data
not yet saved. Counters/integrators are reset (to 0) and
restarted.
