DIGITAL AIR MICROMETER USERS MANUAL (Second Edition)
10
3.4 For several measurement tools connection cases
Shown here is the procedure up to measurement for cases wherein multiple measurement tools are
connected to 1 main body.
Please refer to [Chapter 3, 3.3
For first time measurement tool connection cases] when inputting of
settings for measurement tools that will be connected are not finished.
Replace the measurement tool
Turn ON compressed air
Turn ON power
Switch to program switching
mode
Program switching
Switch to master calibration
mode (detector adjustment)
Adjustment of detector
Switch to master calibration
mode (master calibration)
Master calibration
Measurement
•
Stopping of compressed air to the main body and replace
measurement tool.
Please refer to [Chapter 6, 6.2 Preparation] for details
•
Switch from measurement mode to program switching
mode
Please refer to [Chapter 6, 6.6 Program Switching] for
details
•
At program switching mode, reads the settings value and
master data of the measurement tool connected.
Please refer to [Chapter 6, 6.6 Program Switching] for
details
•
Switch to measurement mode after finishing program
switching.
Please refer to [Chapter 6, 6.6 Program Switching] for
details
