Page 15: Dsp-a inp a dsp-b inp b dsp-c calc, Isplay, Ssignment and, Rogram, Arameters

15
0
COdE
PROGRAM MODE SECURITY CODE*
By entering any non-zero value, the prompt
COdE 0
will appear when trying
to access the Program Mode. Access will only be allowed after entering a
matching security code or universal code of
222
. With this lock-out, a user input
would not have to be configured for Program Lock-out. However, this lock-out
is overridden by an inactive user input configured for Program Lock-out.
LOC
SP-1
LOC
SP-2
LOC
SP-3
LOC
SP-4
SP-1 SP-2 SP-3 SP-4 SETPOINT ACCESS*
The setpoint displays can be programmed for
LOC
,
rEd
or
ENt
(see the
following table). Accessible only with the Setpoint plug-in card installed.
LOC
HI
LOC
LO
LOC
tOt
5.3 MODULE 3 - D
ISPLAY
A
SSIGNMENT AND
P
ROGRAM
L
OCK
-
OUT
P
ARAMETERS
(
3-LOC
)
PARAMETER MENU
*
Factory Setting can be used without affecting basic start-up.
0
to
250
Module 3 is the programming for the Display, Display assignments, Display
lock-out and “Full” and “Quick” Program lock-out.
When in the main Display Mode, the available displays (A,B,C,_) can be
read consecutively by repeatedly pressing the DSP key. An annunciator
indicates the display being shown (_ = No annunciator). A meter display value
can be programmed to one of the displays, to the quick programming mode or
be locked from being visible. It is recommended that the meter display value be
set to
LOC
when it is not being used in the application.
“Full” Programming Mode permits all parameters to be viewed and
modified. This Programming Mode can be locked with a security code and/or
user input. When locked and the PAR key is pressed, the meter enters a Quick
Programming Mode. In this mode, the setpoint values can still be read and/or
changed per the selections below. The display Intensity Level (
d-LEV
)
parameter also appears whenever Quick Programming Mode is enabled and the
security code greater than zero.
Immediate access.
“Full” Programming
Not Active
PLOC
0
No access
Quick Programming
Active
PLOC
0
Immediate access.
“Full” Programming
Not Active
PLOC
>0
After Quick Programming with correct code # at
COdE
prompt.
Quick Programming w/Display Intensity
Active
PLOC
>0
After Quick Programming with correct code # at
COdE
prompt.
Quick Programming w/Display Intensity
————
not
PLOC
>0
Immediate access.
“Full” Programming
————
not
PLOC
0
“FULL” PROGRAMMING MODE ACCESS
WHEN PAR KEY IS
PRESSED
USER INPUT
STATE
USER INPUT
CONFIGURED
SECURITY
CODE
PROGRAMMING MODE ACCESS
Throughout this document, Programming Mode (without Quick in front) always refers to “Full” Programming (all meter parameters are accessible).
SELECTION
DESCRIPTION
ENt
rEd
LOC
dSP-A
INP A
dSP-b
INp b
dSP-C
CALC
DISPLAY ASSIGNMENT
Not visible in Quick Programming Mode Only
Visible in Quick Programming Mode Only
There are six meter values that can be individually programmed for one of
the main displays (A,B,C or _), or programmed to be viewable in Quick
Programming mode (rEd), or programmed to be locked out from display (LOC)
(see the following table). If two or more values are assigned to the same display
the last value assigned will be the one that is displayed.
LOC
rEd
Not visible in Display Mode or Quick Programming Mode
Visible in Quick Programming Mode only
dSP-_
Assign to Display _ (No annunciator)
dSP-A
Assign to Display A
dSP-b
Assign to Display B
dSP-C
Assign to Display C
Visible and changeable in Quick Programming Mode Only
