96
10. Order numbers
Standard Converters Order Number
100 - 240 V AC Smart CE 2107301000
21 - 48 V AC Smart CE 2107303400
24 V DC Smart CE 2107291000
Ex Converters Order Number
100 - 240 V AC Smart CE 2107311000
21 - 48 V AC Smart CE 2107313400
24 V DC Smart CE 2107771000
Power Supply - Fuse F9
Value
Order number Fuse type
160 mA T 5.07379.00 5
×
20 mm G-Fuse
315 mA T 5.05804.00 Switching capacity
800 mA T 5.08085.00 1500 A
1.6 A T 5.07823.00
1.25 A T 5.09080.00 TR 5, switching
capacity 35 A
Fuse Value
F 10 +5 V Analog voltage 500 mA T
F 11 Negative Analog voltage 100 mA T
F 12 Input /output functions 160 mA T
These fuses F10, F11 & 12 are soldered into the power supply and are essential to ensure the
system complies with the European Union’s low voltage directive. Any attempt to replace
these fuses will invalidate the waranty and should not be attempted by the customer. These
fuses will only blow in the event of:
−
Customer abuse, i.e. removing the display with the power still on.
−
Hardware fault
Spares and accessories Order number
1. Special spanner for lid 3.07421.01
2. Lid “O”ring seal
3. RS 232 Adaptor and Config. Software 2.10209.00
4. MIC 500 hand-held communicator 2.07302.00
5. Magnet 2.07053.00
