KROHNE CORIMASS E Series EN User Manual
Page 102
102
11.4.2
Remote Systems - MFS 3081 F / MFS 2081 F
Dimensions
Transducer MFS 3000
Transducer MFS 2000
in mm and (inches)
1.5 E
10 E
30 E
60 P
300 P
800 P
1500 P
a
168....(6.61)
248 (9.76)
356 (14.02)
394 (15.51)
537 (21.14)
810 (31.98)
1152 (45.35)
b
168 (6.61)
248 (9.76)
500 (19.69)
424 (16.69)
596 (23.46)
750 (29.53)
824 (32.44)
c DIN flanges PN40
–
550 (21.65)
740 (29.13)
500 (19.69)
640 (25.20)
950 (37.40)
1300 (51.18)
c ANSI 150/300 RF
–
550 (21.65)
740 (29.13)
500 (19.69)
676 (26.61)
950 (37.40)
1300 (51.18)
c DIN flanges PN63
–
550 (21.65)
740 (29.13)
514 (20.24)
676 (26.61)
982 (38.66)
1328 (52.28)
c Screw
400 (15.75)
475 (18.70)
740 (29.13)
–
–
–
–
d
137 (5.40)
132 (5.20)
171 (6.73)
160 (6.30)
200 (7.87)
270 (10.63)
324 (12.76)
e
169 (6.65)
191 (7.52)
219 (8.62)
192 (7.56)
230 (9.06))
300 (11.81)
339 (13.35)
Weight in kg & (lb)
7 (15)
11 (24)
16.5 (37)
20 (44)
29 (64)
84 (185)
148 (327)
MFS 3000
MFS 2000
Converter - MFC 081 F
