The setting of the display for TOTAL MASS or DENSITY is done the same way.
Temperature is displayed with a fixed position of one decimal place. However, the user can
choose between °C and °F.
Begin from measuring mode
Volume flow is an optional display in the measurement mode. To turn on this display with
units dm3/hr :
For a list of available units for each display refer to Section 5, Technical data.
If a cyclic display of all measurement values is desired the following inputs have to be added
to the previous steps :
With the cyclic display enabled, the converter will switch displays in the measuring mode every
3 to 4 seconds as if the operator had pressed the
↑
key.
Key Display
line 1
line 2
→
Fct. (1).0 OPERATOR
→↑
Fct. 1.(2).0. DISPLAY
5x
↑
Fct. 1.2.(6). TEMPERATUR
→
(°C)
↑
(°F)
↵
Fct. 1.2.(6). TEMPERATUR
Key Display
line 1
line 2
↑
Fct. 1.2.(7) VOL.FLOW.
→
(OFF)
↑
00000.000 (cm3)/S
↑
00000.000 (dm3)/S
→↑↑
00000.000 dm3/(hr)
→
00000(.)000 dm3/ hr
↑↑
0000000(.)0 dm3/hr
↵
Fct. 1.2.(7) VOL.FLOW
Key Display
line 1
line 2
↵→
Fct. 1.2.(1). CYCL. DISP.
→
(NO)
↑
(YES)
↵
Fct. 1.2.(1). CYCL. DISP.
4x
↵
