9
Fig. 6: Installation MFS 3000
A good installation is the basis for the high measurement accuracy of the unit.
The following installation guidelines are practical to implement, particulary if planned before
the CORIMASS is first installed.
2.2 Installation Guidelines
2.2.1 Location of CORIMASS Transducer
Please ensure the following installation guidelines are adhered to as they are absolutely
necessary for good measurement results and trouble-free start-up.
The transducer can be installed in any position. However, when installed in a vertical position
the transducer is self-draining and allows gas bubbles to be readily purged from flowmeter
during flowing conditions (see Fig. 7a and 7b).
