40
Fct. No. Text Description and settings
3.4.0 PULS.OUTP. P Submenu 3.4.0 Frequency output P
3.4.1 FUNCTION P Function frequency output P
* OFF (Output = 0V DC)
* MASS FLOW (Frequency output 0 to MAX Freq. Hz =
Mass Flow in range: MIN. FLOW to MAX FLOW as set
in Fct. 3.4.3 and 3.4.4)
* MASS TOTAL(1 pulse = fixed mass as set in Fct 3.4.2)
* DENSITY (Frequency output 0 to MAX Freq. Hz =
Density in range: MIN.DENSITY to MAX.DENSITY as
set in Fct. 3.4.3 and 3.4.4)
* TEMPERAT. (Frequency output 0 to MAX Freq. Hz =
Temperature in range: MIN. TEMP to MAX. TEMP as
set in Fct. 3.4.3 and 3.4.4)
* VOLUME.FLOW(Frequency output 0 to MAX Freq. Hz
= Volume flow in range: MIN. V.FLOW to MAX.
V.FLOW as set in Fct. 3.4.3 and Fct. 3.4.4)
* VOL.TOTAL(1 pulse = fixed volume as set in Fct 3.4.2)
Solute flow
Solute total Concentration parameters if
Conc. by mass option installed. See separate
Conc. by volume instruction manual.
* DIRECTION (Negative flow gives output of 0 volts DC,
Positive flow gives output of +V volts DC)
3.4.2 PULSE/MASS Mass per pulse value for function TOTAL MASS
or PULSE/VOL. Volume per pulse value for function VOL. TOTAL
or PULSE/TIME Maximum frequency value for functions MASS FLOW,
DENSITY, TEMPERATUR and VOLUME.FLOW or
CONC.OPTIONS. Not accessible for functions OFF and
DIRECTION.
3.4.3 MIN.VALUE Value of measured quantity that corresponds to
or MIN. FLOW, 0 Hz output
or MIN. DENSITY,
or MIN. TEMP.
or MIN. V.FLOW
or CONC.OPTIONS
or PULSE.WIDTH For functions MASS TOTAL, VOL.TOTAL OR
SOL.TOTAL. Not accessible for functions OFF and
DIRECTIONS
3.4.4 Full Scale Value of measured quantity that corresponds to
or MAX. FLOW, Max. Frequency
or MAX. DENSITY
or MAX TEMP.
or MAX V.FLOW
or CONC.OPTIONS Not accessible for functions OFF, DIRECTION, TOTAL
MASS TOTAL, or VOL. TOTAL
}
