Object
No
Index Value (def
ault)
D
esc
ri
pti
on
D
imensi
on
For
mat
min max access Desc
ripto
r
transfe
r
Desc
ript
ion
33y2H 03H 0 Byte no 10 without byte
-128
0
+127
255
r/w - -
10. byte (33y2.01) bit 1 = 0:
signed char (this parameter use the
same memory cell as 30y5.01)
(33y2.01) bit 1 = 1:
unsigned char
33y2H 04H 0 Byte no 11 without byte
-128
0
+127
255
r/w - -
11. byte (33y2.01) bit 2 = 0:
signed char (this parameter use the
same memory cell as 30y5.02)
(33y2.01) bit 2 = 1:
unsigned char
33y2H 05H 0 Byte no 12 without byte
-128
0
+127
255
r/w - -
12. byte (33y2.01) bit 3 = 0:
signed char (this parameter use the
same memory cell as 30y5.03)
(33y2.01) bit 3 = 1:
unsigned char
33y2H 06H 0 Byte no 13 without byte
-128
0
+127
255
r/w - -
13. byte (33y2.01) bit 4 = 0:
signed char (this parameter use the
same memory cell as 30y5.04)
(33y2.01) bit 4 = 1:
unsigned char
33y2H 07H 0 Byte no 14 without byte
-128
0
+127
255
r/w - -
14. byte (33y2.01) bit 5 = 0:
signed char
(33y2.01) bit 5 = 1:
unsigned char
33y2H 08H 0 Byte no 15 without byte
-128
0
+127
255
r/w - -
15. byte (33y2.01) bit 6 = 0:
signed char
(33y2.01) bit 6 = 1:
unsigned char
33y2H 09H 0 Byte no 16 without byte
-127
0
+127
255
r/w - -
16. byte (33y2.01) bit 7 = 0:
signed char
(33y2.01) bit 7 = 1:
unsigned char
34yxH Customer specific 16 bit memory (3 <= y <= 8)
34y1H 00h 9 Number of entries without byte - - r - -
34y1H 01H 0 Data format without byte 0 255 r - -
descriptor for data format bit n = 0:
byte n = signed int, bit n = 1: byte n
= unsigned int
34y1H 02H 0 Word no 1 without word
-32768
0
32767
65535
r/w - -
1. word (34y1.01) bit 0 = 0:
signed int (this parameter use the
same memory cell as 30y3.06)
(34y1.01) bit 0 = 1:
unsigned int
34y1H 03H 0 Word no 2 without word
-32768
0
32767
65535
r/w - -
2. word (34y1.01) bit 1 = 0:
signed int (this parameter use the
same memory cell as 30y5.05)
(34y1.01) bit 1 = 1:
unsigned int
34y1H 04H 0 Word no 3 without word
-32768
0
32767
65535
r/w - -
3. word (34y1.01) bit 2 = 0:
signed int (this parameter use the
same memory cell as 30y3.02)
(34y1.01) bit 2 = 1:
unsigned int
34y1H 05H 0 Word no 4 without word
-32768
0
32767
65535
r/w - -
4. word (34y1.01) bit 3 = 0:
signed int (this parameter use the
same memory cell as 30y3.02)
(34y1.01) bit 3 = 1:
unsigned int
34y1H 06H 0 Word no 5 without word
-32768
0
32767
65535
r/w - -
5. word (34y1.01) bit 4 = 0:
signed int (this parameter use the
same memory cell as 30y3.03)
(34y1.01) bit 4 = 1:
unsigned int
34y1H 07H 0 Word no 6 without word
-32768
0
32767
65535
r/w - -
6. word (34y1.01) bit 5 = 0:
signed int (this parameter use the
same memory cell as 30y3.03)
(34y1.01) bit 5 = 1:
unsigned int
34y1H 08H 0 Word no 7 without word
-32768
0
32767
65535
r/w - -
7. word (34y1.01) bit 6 = 0:
signed int (this parameter use the
same memory cell as 30y3.07)
(34y1.01) bit 6 = 1:
unsigned int
34y1H 09H 0 Word no 8 without word
-32768
0
32767
65535
r/w - -
8. word (34y1.01) bit 7 = 0:
signed int (this parameter use the
same memory cell as 30y3.07)
(34y1.01) bit 7 = 1:
unsigned int
