HARTÆ Communications Protocol
IFC010 Command Specification Rev: 1.0 Release Date: 29 May 1997
© 1997 KROHNE Mefltechnik D-47058 Duisburg Page 18
3-4 Undefined
5 Too Few Data Bytes Received
6-127 Undefined
8.10 Command #139 Write Analog Output Function
Writes the function of current/pulse output.
REQUEST DATA BYTES
#0 #1
ANALOG ANALOG
OUTPUT OUTPUT
NUMBER FUNCTION
CODE CODE
RESPONSE DATA BYTES
#0 #1
ANALOG ANALOG
OUTPUT OUTPUT
NUMBER FUNCTION
CODE CODE
Data Byte #0 Analog Output Number Code, equals м1о for current output and м2о - for pulse output
Data Byte #1 Analog Output Function Code, valid settings:
0 - Off,
1 - 1 Dir, output traces flowrate measurements only in one (forward) direction,
3 - 2 Dir, output traces flowrate measurements in both directions.
NOTE: In the case of incorrect function the request will be rejected with a response code 3, Passed Parameter too Large.
COMMAND-SPECIFIC RESPONSE CODES
0 No Command-Specific Errors
1 Undefined
2 Invalid Selection
3 Passed Parameter too Large
4 Undefined
5 Too Few Data Bytes Received
6 Undefined
7 In Write Protect Mode
8 Update Failure
9-127 Undefined
8.11 Command #142 Read Pulse Output Parameters
Reads adjustment parameters of the pulse output: PulseType, PulseWidth, PulseValue.
REQUEST DATA BYTES
NONE
RESPONSE DATA BYTES
#0 #1 #2 ... #5
PULSE PULSE PULSE PULSE
TYPE WIDTH VAL VAL
MSB LSB
Data Byte #0 Pulse type, defines how pulses are generated at the output:
