OPERATION
4
25
OPTISENS COND 1200
www.krohne.com
01/2014 - 4001967301 - MA OPTISENS COND 1200 R01 en
B1,sim.process inp.A
B2,sim.process inp.B
B4, actual values
B6, information
4.2.3 Menu C, setup
Level
Designation / function
Settings / descriptions
B1.1
B1.1
B1.1
B1.1
temperature
In this menu the temperature can be simulated.
B1.2
B1.2
B1.2
B1.2
spec. conductivitiy
In this menu the conductivity can be simulated.
B1.3
B1.3
B1.3
B1.3
spec. resistance
In this menu the resistance can be simulated.
Level
Designation / function
Settings / descriptions
This menu groups several functions which allow to display the corresponding actual reading. The shown measurements
are depending on the device configuration.
B4.2
B4.2
B4.2
B4.2
process input A
In this menu the measurements from process input A can be read.
B4.3
B4.3
B4.3
B4.3
process input B
In this menu the measurements from process input B can be read. (for 2
channel version only)
Level
Designation / function
Settings / descriptions
This menu groups several other menus which contain device specific information. The build-up of the display is the
same for all menus:
•
1
st
line: ID No. of the circuit board
•
2
nd
line: software version
•
3
rd
line: production date
B6.2
B6.2
B6.2
B6.2
process input A
Gives information about the electronical part of process input A.
B6.3
B6.3
B6.3
B6.3
process input B
In this menu the measurements from process input B can be read. (for 2
channel version only)
INFORMATION!
The signal converter has a dual process input, A and B. Each process input has an own submenu
in this main menu. Process input A is always present, i.e. there is always a board in the interface
"Pos.A" in the connection area. The interface of process input B only has a board with the dual
channel signal converter. Be aware that the definition which kind of measurement a process
input can do is defined when ordering the device. The configuration cannot be changed later.
INFORMATION!
Note that the appearance of some submenus depends on the hardware setting and the used
sensor(s).
