Installation, 8 examples of a typical measuring point – KROHNE OPTISENS COND 1200 EN User Manual
Page 22
3
INSTALLATION
22
OPTISENS COND 1200
www.krohne.com
01/2014 - 4001967301 - MA OPTISENS COND 1200 R01 en
3.8 Examples of a typical measuring point
The following examples each show the signal converter, a sensor with integrated temperature
sensor, and the flow-through or immersion assembly.
1 Bypass measurement
2 Inlet measurement
3 Shut-off valve
4 Flow-through assembly with sensor
5 Bypass pipe
6 Main pipe
Figure 3-11: Installation with signal converter
1 Single channel version
2 Dual channel version
.book Page 22 Friday, January 24, 2014 12:32 PM
