35
Pressing ENTER now will make the instrument search for a
temperature signal. If this is not found then the display will read
the following. ATTACH SENSORS yy-mm-dd hh:mm:ss
No signal from temp sensor
Press ENTER to try again or
SCROLL to enter a value
The user can now enter a temperature value between -20
°
C and +220
°
C, press ENTER for the separation distance.
The display will now read the following. The temperature will only
be shown on this display if entered manually. ATTACH SENSORS yy-mm-dd hh:mm:ss
FLUID TEMPERATURE (
°
C) 20.0
Set sensor separation to 33.5
Press ENTER to continue
Now set the transducers to the required separation distance.
Pressing ENTER will take the instrument into flow mode. READ FLOW yy-mm-dd hh:mm:ss
ERROR MESSAGES APPEAR HERE
Battery
100%
Signal
100%
Temp
+ Total 1564 l
20
°
C - Total l
100.0
l/m
