TECHNICAL DATA
66
WATERFLUX 3070
www.krohne.com 06/2013 - 4001410205 - HB WATERFLUX 3070 R05 en
Signal cable Signal cable Signal cable Signal cable (remote versions only)
Type KROHNE WSC cable
Length Standard: 5m
Optional: 10m, 15m, 20m, 25m
In- and output In- and output In- and output In- and output
Pulse output 2 Passive pulse outputs (maximum 3 outputs possible; see status output)
f ≤ 100 Hz; I ≤ 10 mA; U: 2.7…24 VDC (P ≤ 100 mW)
Volume / pulse is programmable
Phase shift between pulse A and B (forward and reverse) selectable
Pulse width is selectable:
5 ms (default), 10 ms, 20 ms, 50 ms, 100ms, 200 ms
Status output 2 Passive status outputs (1 status output can be used as a third pulse
output)
I ≤ 10 mA; U: 2.7…24 VDC (P ≤ 100 mW)
Function (selectable): self check, battery pre warning, battery final
warning, empty pipe
Communication Optional: KGA 42 external datalogger / GSM module
For detailed information refer to the KGA 42 documentation.
Approvals and certificates
CE CE CE CE
This device fulfils the statutory requirements of the EC directives. The
manufacturer certifies successful testing of the product by applying the CE
mark.
Electromagnetic
compatibility
Directive: 2004/108/EC
Harmonized standard: EN 61326-1: 2006
Pressure Equipment
Directive
Not applicable: networks for the supply, distribution and discharge of
water and associated equipment are excluded from the scope of this
directive.
Other approvals and standards Other approvals and standards Other approvals and standards Other approvals and standards
Custody transfer
( DN25...300)
MID Annex MI-001 type examination certificate
OIML R49 certificate of conformity
Conformity with ISO 4064 and EN 14541
Innerstaatliche Bauartzulassung als Kaeltezaehler (For Germany,
Switserland and Austria).
DN40...100; SANS 1529 (South Africa)
Drinking water approvals ACS, DVGW W270, NSF / ANSI Standard 61, TZW, WRAS
Protection category acc. to
IEC 529 / EN 60529
Compact version (C) in polycarbonate housing: IP68 (NEMA 4X/6P)
(Test conditions; 1500 hours, 10 meters below surface)
Compact version (C) in aluminium housing: IP66/67 (NEMA 4/4X/6)
Field version (F) in aluminium housing: IP66/67 (NEMA 4/4X/6)
Shock test IEC 68-2-27
30 g for 18 ms
Vibration test IEC 68-2-64
f = 20 - 20000 Hz, rms = 4.5g, t = 30 min.
