6
OPERATION
50
WATERFLUX 3070
www.krohne.com 06/2013 - 4001410205 - HB WATERFLUX 3070 R05 en
24 Pulse output A and B:
pulse value
00100 = litre Unit and format are automatically
set based on the selection made in
menu number 10. 00.100 = m 3 /pulse
0010.0 = gallon
0010.0= imp. gallon
001.00 = ft
3
.00100 = a-inch
.00100 = a-ft
25 Pulse output A and B:
pulse generation
99 = Automatically set (default) Pulse output reacts as set in menu
number 24
1 *******1 (A pulse is generated if the
least significant digit changes)
2 ******2*
3 *****3**
4 ****4***
5 ***5****
6 **6*****
7 *7******
8 8******* (A pulse generated if the
most significant digit changes)
30 Pulse output C 0 = Status output (default) Sets status output 1 as status output
(select 0) or as pulse output (select 1,
2 or 3).
1 = Forward counter
2 = Reverse counter
3 = Net forward volume
31 Pulse output C:
unit of volume
00 = Litre (l)
01 = Cubic meter (m 3 ) (default)
02 = Gallon (gal)
03 = Imperial gallon (i.gal)
04 = Cubic feet (ft
3
)
05 = Acre feet (a-ft)
06 = Acre inch (a-in)
32 Pulse output C:
pulse width
5 = 5 ms (default) A small pulse width means a lower
energy consumption of the battery.
10 = 10 ms
20 = 20 ms
50 = 50 ms
100 = 100 ms
200 = 200 ms
33 Pulse output C:
pulse value
00100 = litre Unit and format are automatically
set based on the selection made in
menu number 10. 00.100 (default) = m 3 / pulse
0010.0 = gallon
0010.0 = imp. gallon
001.00 = ft 3
.00100 = a-inch
.00100 = a-ft
No. Function Options Description
