4.3.4 PROGRAM MESSAGE STRUCTURE
SCPI program messages (commands from controller to power supply) consist of one or more
message units ending in a message terminator (required by Kepco power modules). The message
terminator is not part of the syntax; it is defined by the way your programming language indi-
cates the end of a line (such as a “newline” or “end-of-line” character). The message unit is a
keyword consisting of a single command or query word followed by a message terminator (e.g.,
CURR? or TRIG). The message unit may include a data parameter after
the keyword separated by a space; the parameter is usually numeric (e.g., CURR 5),
but may also be a string (e.g., OUTP ON). Figure 4-2 illustrates the message struc-
ture, showing how message units are combined. The following subparagraphs explain each
component of the message structure.
NOTE: An alternative to using the message structure for multiple messages defined in the fol-
lowing paragraphs is to send each command as a separate line. In this case each
command must use the full syntax shown in Appendix B.
TABLE 4-4. SCPI COMMAND INDEX
COMMAND PAGE COMMAND PAGE
*CLS A-1 [SOUR]:CURR? B-5
*ESE A-2 [SOUR]:CURR:TRIG B-6
*ESE? A-2 [SOUR]:CURR:TRIG? B-6
*ESR? A-3 [SOUR]:VOLT B-7
*IDN? A-3 [SOUR]:VOLT? B-7
*OPC A-4 [SOUR]:VOLT:TRIG B-8
OPC? A-4 [SOUR]:VOLT:TRIG? B-8
*RST A-5 [SOUR]:FUNC:MODE B-9
*SRE A-6 STAT:OPER:COND? B-9
*SRE? A-6 STAT:OPER:ENAB B-10
*STB? A-7 STAT:OPER:ENAB? B-10
*TRG A-7 STAT:OPER? B-11
*TST A-8 STAT:PRES B-11
*WAI A-8 STAT:QUES? B-12
INIT[:IMM] B-1 STAT:QUES:COND? B-12
INIT:CONT B-1 STAT:QUES:ENAB B-13
INIT:CONT? B-2 STAT:QUES:ENAB? B-13
MEAS:CURR? B-3 SYST:ERR? B-14
MEAS:VOLT? B-3 SYST:LANG B-14
[SOUR]:CURR B-4
