1-2
BIT 4882 SVC 030507
1.3 SPECIFICATIONS, BIT 4882, BIT 4882-F AND BIT 4886 (SEE TABLE 1-3)
TABLE 1-2. APPLICABILITY OF BIT 4882, 4882-F AND BIT 4886 CARDS
TO SPECIFIC BOP MODELS
BOP TO BE MODIFIED
APPLICABLE
CARD
BOP TO BE MODIFIED
APPLICABLE
CARD
MODEL REVISION NO. MODEL REVISION NO.
20-5M
1 BIT 4882-F
50-8M
4 TO 9 BIT 4882-F
2 AND LATER BIT 4882 10 AND LATER BIT 4882
20-10M
12 TO 16 BIT 4882-F
72 3M
5 TO 9 BIT 4882-F
17 AND LATER BIT 4882 10 AND LATER BIT 4882
20-20M
8 TO 14 BIT 4882-F
72-6M
7 TO 13 BIT 4882-F
15 AND LATER BIT 4882 14 AND LATER BIT 4882
36-6M
12 TO 18 BIT 4882-F
100-1M
17 TO 23 BIT 4882-F
19 AND LATER BIT 4882 24 AND LATER BIT 4882
36-12M
7 TO 12 BIT 4882-F
100-2M
10 TO 14 BIT 4882-F
13 AND LATER BIT 4882 15 AND LATER BIT 4882
50-2M
16 TO 20 BIT 4882-F
100-4M
6 TO 13 BIT 4882-F
21 AND LATER BIT 4882 14 AND LATER BIT 4882
50-4M
6 TO 12 BIT 4882-F
200-1M
6 AND EARLIER BIT 4882-F
13 AND LATER BIT 4882 7 AND LATER BIT 4882
NOTE: For modification of BOP Models with revision numbers that do not appear in this table, contact Kepco for assistance.
TABLE 1-3. SPECIFICATIONS, BIT 4882, BIT 4882-F AND BIT 4886
SPECIFICATION DESCRIPTION
OUTPUT VOLTAGE (MAIN CHANNEL) 0 ± 10V
OUTPUT VOLTAGE (LIMIT CHANNEL) 0 to +10V
OUTPUT CURRENT (EACH CHANNEL) 0 to ± 2 mA max.
OUTPUT IMPEDANCE <0.05 ohms
TEMPERATURE COEFFICIENT
Full scale: ± 35 ppm/°C max
Zero:
± 20 µV/°C max
OPTICAL ISOLATION
Digital and Analog grounds can be separated by a
maximum of 500 Volts.
DIGITAL INPUT FORMAT Byte-Serial
POWER REQUIREMENT Supplied by BOP
RATING/DESCRIPTION CONDITION
PRGRAMMING RESOLUTION
VOLTAGE
0.024% 12 Bits
CURRENT
DATA READBACK ACCURACY
VOLTAGE
BIT 4882, 4882-F: 0.1%
BIT 4886:
0.2%
% of Max. Voltage
or Max. Current
CURRENT
