FIGURE B-15. STATus:OPEReration:ENABle COMMAND
FIGURE B-16. STATus:OPEReration:ENABle QUERY
Syntax:
Short Form:
STAT:OPER:ENAB
Long Form:
STATus:OPERation:ENABle
Function:
Programs Operational Condition Enable Register)
Description:
The Operation Condition Enable Register determines which conditions are allowed to set the Opera-
tion Condition Register. The value sent by the controller sets the corresponding bits of the Operation
Condition Enable Register in the power supply (1 = set = function enabled, 0 = reset = function dis-
abled).
Example:
STAT:OPER:ENAB 1280
Bits 8 and 10 of Operation Condition Enable Register are set, allowing
the Operation Condition Register to monitor Voltage and Current mode
conditions, but not report the status of the relay.
OPERATION CONDITION ENABLE REGISTER BITS
CONDITION
CURRENT
MODE
RELAY
CLOSED
VOLTAGE
MODE
NOT USED
BIT
10
9
8
7
6
5
4
3
2
1
0
VALUE
1024
512
256
128
64
32
16
8
4
2
1
STAT:OPER:ENAB
Syntax:
Short Form:
STAT:OPER:ENAB?
Long Form:
STATus:OPERation:ENABle?
Function:
Reads Operational Condition Enable Register)
Description:
Power supply returns value of Operation Condition Enable Register to controller, indicating which con-
ditions are being monitored. (1 = set = function enabled, 0 = reset = function disabled)
Example:
STAT:OPER:ENAB?
Controller reads
8, 9, and 10 of the Operation Condition Register are set, allowing
Voltage mode, relay closed, and Current mode conditions to be
monitored.
OPERATION CONDITION ENABLE REGISTER BITS
CONDITION
CURRENT
MODE
RELAY
CLOSED
VOLTAGE
MODE
NOT USED
BIT
10
9
8
7
6
5
4
3
2
1
0
VALUE
1024
512
256
128
64
32
16
8
4
2
1
STAT:OPER:ENAB?
