FIGURE B-7. CURRent:TRIGgered COMMAND
FIGURE B-8. CURRent:TRIGgered QUERY
Syntax:
Short Form:
CURR:TRIG
Long Form:
[SOURce]:CURRent:TRIGgered
Function:
Programs current value to be implemented by *TRG command. Actual output current will depend on
load conditions.
Description:
This command can be used to reset many power supplies to preselected parameters by issuing a sin-
gle *TRG command.
Example:
VOLT 21; CURR 1.1
Power supply commanded to go to 21V, 1.1A
CURR:TRIG 2.3
Power supply current programmed to 2.3A upon receipt of *TRG
CURR?
Controller reads 1.1, indicating programmed current value = 1.1A
*TRG
Power supply commanded to current value established by CURR:TRIG
command (2.3) and voltage value established by VOLT:TRIG
CURR?
Controller reads 2.3, indicating programmed current value = 2.3A
CURR:TRIG
Syntax:
Short Form:
CURR:TRIG?
Long Form:
[SOURce]:CURRent:TRIGgered?
Function:
Returns value to controller which represents current value to be programmed by *TRG command.
Description:
This command returns the current value established by CURR:TRIG command.
Example:
VOLT 21; CURR 1.1
Power supply commanded to go to 21V, 1.1A
CURR:TRIG 2.3
Power supply current programmed to 2.3 upon receipt of *TRG
CURR?
Controller reads 1.1, indicating programmed current value = 1.1A
CURR:TRIG?
Controller reads 2.3 (current value established by CURR:TRIG
command
CURR:TRIG?
