PVCHECK
EN - 56
6. For M
 test in STRING mode there are the values of the
following parameters:
 Set rated test voltage
 Minimum threshold set on insulation measurement
 The type of mode selected
 The real value of the applied test voltage
 The Rp final value of the measurement obtained by
the parallel of Ri(+) e Ri(-) values which is compared
with the Ri min limit by the instrument
15/05/12 15:34:26
I n s . T e s t : 1 0 0 0 V
R i m i n : 1 . 0 M 
M o d e : S t r i n g
V t e s t 1 0 2 0 V
R p > 2 0 0 M

Outcome: OK
Selection M

7. For LOW
 test, there are the values of the following
parameters:
 Limit threshold set for continuity measurement
 Value of calibration resistance of test cables
 The value of resistance of the object being tested
 The real value of the applied test current
15/05/12 15:34:26
R P E m a x : 1 . 0

R c a l : - - - 
R p e = 0 . 9 9

I t e s t = 2 1 2 . m A
Outcome: OK
Selection L O W

7.3.3. Deleting data from the memory
1. Within the list of saved results, press ENTER to display
the submenus.
2. Select “Delete”, then press
. The instrument allows
selecting the following items:
 Delete Last  deletes the last saved test
 Delete All  deletes the whole memory content
3. Use the arrow keys (
,) to select the desired option,
then press the ENTER key to confirm selection
4. Press ESC/MENU to exit the screen and go back to the
main menu.
15/05/12 15:34:26
MEM TYPE
001 SMP 08/04/2012
002 REC 13/04/2012
R e c a l l 
O p e n D e l e t e L a s t
D e l e t e D e l e t e A l l
Selection MEM EFF
