PVCHECK
EN - 51
7. STORING DATA
The instrument allows saving max 999 measured values. The saved data can be recalled
at display and deleted at any moment, and can be associated to reference numerical
markers relevant to the installation name, the PV string and the PV module (max 250
markers).
7.1.
SAVING EFFICIENCY MEASURES
1. Press the SAVE key with a measured result shown on the
display. The instrument shows the screen to the side,
containing a virtual keyboard.
2. Use the arrow keys (
,) and ( , ) to add a short
description (max 13 chars) relevant to the test performed.
3. Press the SAVE key again to confirm data saving or
ESC/MENU to exit without saving.
15/05/12 15:34:26
I r r 7 1 2 W / m 2
P n o m 3 . 5 0 0 k W
T c 4 5 ° C
T e 3 0 ° C
P d c 3 . 1 2 5 k W
K E Y B O A R D
P V P L A N T
A B C D E F G H I J K L M N O P
Q R S T U V W X Y Z - + 0 1 2 3
4 5 6 7 8 9 S P A C E
D E L
SAVE/ESC
7.2. SAVING IVCK, M
 AND LOW MEASURED RESULTS
1. Press the SAVE key with a measured result shown on the
display. The instrument shows the screen to the side,
containing the following items:
 The first memory location available (“MEASURE”)
 The 1
st
marker level (ex: Area)
 The 2 nd
marker level (ex: Field)
 The 3 rd
marker level (ex: Inverter)
 The field “Comment” in which the operator can include
a short description (max 13 char) for the system.
15/05/12 15:34:26
M E A S U R E : 0 0 4
A r e a :  0 0 1 
F i e l d : 0 0 1
I n v e r t e r : 0 0 1
C o m m e n t :
M o d i f i c a t i o n S A V E
2. Each marker level can be assigned to different labels (5
labels are built-in and 5 labels can be customized). Select
the desired marker level using the arrow keys (
 , ) and
press the ENTER key to get available strings.
3. Select one of the items available using the arrow keys
(
,) and confirm with ENTER.
Inverter
Area 0 0 4
Building  0 0 2 
Field 0 0 1
Plant 0 0 1
C o m m e n t :
M o d i f i c a t i o n S A V E
4. Before performing a test, by mean Topview PC software,
it’s possible to add custom strings into the list of marker
level strings. In this case, the new values may be selected
as an alternative to the buil-in ones, as shown in the
screen to the side.
Solar Power
PVPlant factory 0 0 4
HT instruments  0 0 2 
HT ITALIA 0 0 1
PV installation 0 0 1
Inverter
Area
Building
Field
Plant
M o d i f i c a t i o n S A V E
