PVCHECK
EN - 18
5.5. IVCK – SETTINGS FOR IVCK QUICK TEST
The purpose of this measurement is to verify the functionality of the connections and of the
strings in a photovoltaic field, according to the provisions of standard IEC/EN62446 by
measuring the open circuit voltage and the short-circuit current at operating conditions and
referred to STC (via the optional measurement of irradiation) and providing immediate
results regarding the measurement just carried out, both in absolute terms and by
comparison with the strings previously tested. The test also allows carrying out (if selected)
the continuity test and an insulation measurement in a sequence.
5.5.1. Instrument settings
1. Position the cursor onto IVCK by using the arrow keys
(
,) and confirm with ENTER. The display shows the
following screen:
15/05/12 15:34:26
M o d u l e : S U N P W R 3 1 8
V d c : 0 . 0 V
I r r : 0 W / m 2
T c : A u t o ° C
V o c , I s c :
R i ( 1 0 0 0 V ) = - - - M

R p e ( C a l ) = - - - 
Selection I V C K
2. Press the ENTER key. The instrument shows the
following options: Settings, Reset Averages (see §
6.3.4) and Leads calibration (see § 6.5.2).
3. Use the arrow keys (
,) to select “Settings” and
confirm with ENTER. The instrument shows the following
screen:
15/05/12 15:34:26
M o d u l e : S U N P W R 3 1 8
V d c : 0 . 0 V
I r r : 0 W / m 2
T c : A u t o ° C
V o c , I s c :
R i ( 1 0 0 0 V ) = - - - M

R p e ( C a l ) = - - - 
Leads calibration
Reset Averages
Settings
Selection I V C K
4. Use the arrow keys (
,) for option setting, and select
the desired option by means of the arrow keys (
 , ).
The following parameters can be set:
 Module  type of module being tested
 Mod. N x Str.  number of modules in the string.
Allowable values 1
 50
 Temp  temperature measuring method. Possible
options:
“Auto”
 automatic measurement (recommended)
carried out according to the measured value of the
15/05/12 15:34:26
M o d u l e :  S U N P W R 2 1 0 
M o d . N x S t r : 0 1
T e m p :
M a n u a l
2 5 ° C
T o l . V o c : 0 5 % ( + 4 % )
T o l . I s c : 0 5 % ( + 4 % )
I n s . T e s t : 1 0 0 0 V
R i m i n : 1 . 0 M

R P E T e s t : 2

S A V E t o s t o r e
I V C K
