PVCHECK
EN - 48
Fig. 14: Connection for continuity measurement on structures of the PV installation
CAUTION
Upon pressing the GO/STOP key, different error messages can be displayed
by the instrument (see § 6.6) and, therefore, the test cannot be started. Check
and eliminate, if possible, the problem causing the error message before going
on with the test.
5. Press GO/STOP to start the test. In case no error
conditions occur, the instrument displays the message
“Measuring…” as shown in the screen to the side.
15/05/12 15:34:26
R P E m a x
:
1 . 0
R c a l
:
- - -
R p e
=
- - -
I t e s t
=
- - -
m A
Measuring…
Selection
L O W
6. At the end of measurement, the instrument provides the
value of resistance of the object being tested. If the result
is lower than the maximum limit set, the instrument
displays the message “Outcome:OK”; otherwise, it
displays the message “Outcome:NO” as shown in the
screen to the side.
7. Press the SAVE key to store the test result in the
instrument’s memory (see § 7.2) or the ESC/MENU key to
exit the screen without saving and go back to the main
measuring screen.
15/05/12 15:34:26
R p e m a x
:
1 . 0
R c a l
:
- - -
R p e
= 0 . 2 3
I t e s t
= 2 1 0
m A
Outcome: OK
Selection
L O W
